Data sheet
Article number
Select a color, please
Pole light 3-light
type ..2073
€1.086,00
Manufacturer's Suggested Retail Price excl. VAT
Material housing
Aluminium
Colour housing
Black, White
Lamp type
HV halogen lamp
Lamp holder
E27
Suitable for lamp power
1 - 225 W
Material cover
Glass opal
Pole included
Ja
Weight | N/A |
---|---|
Mounting Type | Post top |
Degree of protection (IP) | IP44 |
Suitable for number of lamps | 3 |
Nominal voltage | 230 V |
Voltage type | AC |
Dimming phase cut-off | Yes |
Type of control gear | Not required |
Surface protection | Lacquered |
Height | > 1700 mm |
Dimming phase cut-on | Yes |
Connection type | Screwed terminal |
Rated ambient temperature according to IEC62722-2-1 | 15 – 25 °C |
Max. system power | 225 W |
Protection class | I |
No dim function | Yes |
Power factor | 1 |
Height/depth | 2200 mm |
Light type | Standleuchte |
Cable length | 0 m |
Type of wiring | Suitable for through wiring |
Diameter | 860 mm |
Style | Edelstahl, Modern |
Number of poles | 3 |
Conductor cross section | 2.5 mm² |
Highest energy efficiency class of the exchangeable lamp | A++ |
Lowest energy efficiency class of the exchangeable lamp | E |
Shape | Eckig |
