Data sheet
Wall light Anthracite Product Image Article 620333
Wall light Dimensioned drawing Article 620333, 660333, 680333, 690333
Wall light Anthracite Product Image Article 620333
Wall light Dimensioned drawing Article 620333, 660333, 680333, 690333
Wall light Dimensioned drawing Article 620333, 660333, 680333, 690333
Wall light Dimensioned drawing Article 620333, 660333, 680333, 690333
Wall light Dimensioned drawing Article 620333, 660333, 680333, 690333
Article number Select a color, please

Wall light

type ..0333

€193,00 – €222,10

Manufacturer's Suggested Retail Price excl. VAT

Find Retailer

Clear
Features
IP54 Product-Icon Luminaire has IP 54 protection.
Luminaire has IP 54 protection.
LED Product-Icon Luminaire is equipped with LED components.
Luminaire is equipped with LED components.
LED Replaceable Product-Icon LED components can be replaced.
LED components can be replaced.
Overvoltage protection Product-Icon Luminaire is equipped with increased or additional overvoltage protection.
Luminaire is equipped with increased or additional overvoltage protection.
Material housing
Aluminium
Colour housing
Anthracite, Black, Silver, White
Lamp type
LED exchangeable
With light source
Yes
Suitable for lamp power
5 W
Rated luminous flux according to IEC 62722-2-1
480 lm
Colour temperature
3000 K
Material cover
Plastic, opal
Documents and files
Assembly instruction
download PDF 90.94 KB
Dimensioned drawing
download PDF 55.8 KB
Light distribution curve - Eulumdat/LDT
download LDT 9.77 KB
Offertext
For: 620333
download TXT 254 B
Offertext
For: 660333
download TXT 249 B
Offertext
For: 680333
download TXT 249 B
Offertext
For: 690333
download TXT 233 B
Full catalog 21 / 22
download PDF 38.74 MB
Spare parts
90270493 - G 493, acrylic glass pane white show

Additional information

Weight N/A
Suitable for wall mounting

Yes
Beam angle

Open beam/diffuse
Nominal voltage

230 V
Type of control gear

LED operating device voltage-controlled
Voltage type

AC
With light source

Yes
Suitable for lamp power

5 W
Number of poles

3
Suitable for surface mounting

Yes
Colour housing

Anthracite, Black, Silver, White
Light output

Direct
Height/depth

40 mm
Max. system power

5 W
Material cover

Plastic, opal
Material housing

Aluminium
With control gear

Yes
Lamp type

LED exchangeable
Power factor

0.9
Suitable for number of lamps

1
Width

200 mm
Dimming phase cut-off

Yes
Conductor cross section

2.5 mm²
Light type

Wandleuchte
Light sharing

Symmetric
Energy efficiency class of the provided exchangeable built-in lamp

E
Type of wiring

Ending
Colour rendering index CRI

80-89
Degree of protection (IP)

IP54
Light output

1-seitig
Max. number of luminaires per miniature circuit breaker C16

30
Flickering value Pst LM

1
Exchangeable control gear

Yes
Protection class

I
Rated ambient temperature according to IEC62722-2-1

15 – 25 °C
Connection type

Screwed terminal
Colour temperature

3000 K
Colour of light

White
Rated luminous flux according to IEC 62722-2-1

480 lm
Height

< 700 mm
Dimming depending on control gear

Yes
Max. number of luminaires per miniature circuit breaker B16

20
Highest energy efficiency class of the exchangeable lamp

A++
Style

Modern
Surface protection housing

Lacquered
Length

105 mm
Mounting Type

Wand
Stroboscope effect value SVM

0.4
No dim function

Yes
Colour consistency (McAdam ellipse)

SDCM3
Photobiological safety according to EN 62471

RG1
Lowest energy efficiency class of the exchangeable lamp

E
Unified Glare Ratio (UGR)

1
Shape

Eckig
