Data sheet
Article number
Select a color, please
Spit lamp
type ..2433
€216,80 – €249,40
Manufacturer's Suggested Retail Price excl. VAT
Features
Luminaire can be operated with 230 V, 0/50-60 Hz.
Luminaire has IP 54 protection.
Luminaire is equipped with LED components.
LED components can be replaced.
Material housing
Aluminium
Colour housing
Anthracite, Black
Lamp type
LED exchangeable
With light source
Yes
Suitable for lamp power
4 W
Rated luminous flux according to IEC 62722-2-1
230 lm
Colour temperature
3000 K
Material cover
Glass transparent
| Weight | N/A |
|---|---|
| Light sharing | Symmetric |
| Conductor cross section | 0 mm² |
| Number of poles | 3 |
| Connectable conductor cross section | 0 mm² |
| Protection class | I |
| Power factor | 0.9 |
| Colour of light | White |
| Luminous flux | 230 lm |
| Rated ambient temperature according to IEC62722-2-1 | 15 – 25 °C |
| Degree of protection (IP) | IP54 |
| Colour rendering index CRI | 80-89 |
| Unified Glare Ratio (UGR) | 1 |
| Max. number of luminaires per miniature circuit breaker C16 | 30 |
| Max. number of luminaires per miniature circuit breaker B16 | 20 |
| Stroboscope effect value SVM | 0.4 |
| Beam angle adjustable | Continuously variable |
| Flickering value Pst LM | 1 |
| Exchangeable control gear | Yes |
| Light outlet | 1-seitig |
| Mounting method | Spieß |
| Shape | Eckig |
| Colour consistency (McAdam ellipse) | SDCM3 |
| Energy efficiency class of the provided exchangeable built-in lamp | E |
| Light outlet | Direct |
| Dimming phase cut-off | Yes |
| Suitable for number of lamps | 1 |
| Type of control gear | LED operating device voltage-controlled |
| Voltage type | AC/DC |
| Suitable for pedestal/floor mounting | Yes |
| Beam angle | Medium beam 21-40° |
| With control gear | Yes |
| Light distributor | Reflector |
| No dim function | Yes |
| Outer diameter | 40 mm |
| Type of wiring | Ending |
| Length | 100 mm |
| Max. system power | 4 W |
| Surface protection | Lacquered |
| Nominal voltage | 230 V |
| Adjustability | Not adjustable |
Documents and files
Spare parts
| 90220488 - G 488, glass pane d = 40 x 3 mm ESG | show |
Additional information
| Weight | N/A |
|---|---|
| Light sharing | Symmetric |
| Conductor cross section | 0 mm² |
| Number of poles | 3 |
| Connectable conductor cross section | 0 mm² |
| Protection class | I |
| Power factor | 0.9 |
| Colour of light | White |
| Luminous flux | 230 lm |
| Rated ambient temperature according to IEC62722-2-1 | 15 – 25 °C |
| Degree of protection (IP) | IP54 |
| Colour rendering index CRI | 80-89 |
| Unified Glare Ratio (UGR) | 1 |
| Max. number of luminaires per miniature circuit breaker C16 | 30 |
| Max. number of luminaires per miniature circuit breaker B16 | 20 |
| Stroboscope effect value SVM | 0.4 |
| Beam angle adjustable | Continuously variable |
| Flickering value Pst LM | 1 |
| Exchangeable control gear | Yes |
| Light outlet | 1-seitig |
| Mounting method | Spieß |
| Shape | Eckig |
| Colour consistency (McAdam ellipse) | SDCM3 |
| Energy efficiency class of the provided exchangeable built-in lamp | E |
| Light outlet | Direct |
| Dimming phase cut-off | Yes |
| Suitable for number of lamps | 1 |
| Type of control gear | LED operating device voltage-controlled |
| Voltage type | AC/DC |
| Suitable for pedestal/floor mounting | Yes |
| Beam angle | Medium beam 21-40° |
| With control gear | Yes |
| Light distributor | Reflector |
| No dim function | Yes |
| Outer diameter | 40 mm |
| Type of wiring | Ending |
| Length | 100 mm |
| Max. system power | 4 W |
| Surface protection | Lacquered |
| Nominal voltage | 230 V |
| Adjustability | Not adjustable |
